Beneteau Swift Trawler 35 – Motor yacht
Photo: Bengt Nyman from Vaxholm, Sweden, CC BY 2.0, via Wikimedia Commons

Beneteau · Motor yacht

Beneteau Swift Trawler 35

The Swift Trawler 35 is the 11.29 m flybridge model of Beneteau’s Swift Trawler range, built by Beneteau (SPBI) in France from 2017 until the Swift Trawler 37 replaced it in 2025: a semi-planing motor yacht with naval architecture by Beneteau Power and styling by Andreani Design. Every boat has a single Cummins QSB6.7 of 425 hp on a shaft, a bow thruster and electric trim tabs, an 800 l fuel tank, an owner’s cabin forward, a bunk cabin and one head. Its predecessor, the Swift Trawler 34 of 2009 to about 2017 (Fly, and the 34 S without a helm on the flybridge), had the same single-Cummins layout on a 10.98 m hull; Beneteau counts more than 350 of them. Generator, stern thruster and windlass were options in Europe but standard on North American boats, so the equipment differs from boat to boat.

Manuals & documents

The links go to Beneteau’s own documents — some as archived copies of pages the maker has since taken down. We host no manuals or drawings.

Equipment & its manuals

Standard equipment as the builder’s documents list it. Boats were ordered with options and refitted since — check what is actually aboard.

ItemModelManual / pageNote
EngineCummins QSB6.71,2,3,4,5Swift Trawler 35, every list from 2017 to 2024: one engine of 425 hp (313 kW) on a shaft, the only engine Beneteau offered—Beneteau writes ‘QSB6.7I’. A fuel filter with water separator and a sea-water filter are standard. Manuals and certificates for the engine come from Cummins and its dealers, not from Beneteau.
EngineCummins QSB5.96,7Predecessor Swift Trawler 34: 425 hp (313 kW) on a shaft with a 4-blade propeller in the provisional list of June 2009; 330 hp in the January 2010 list of the 34 S—Beneteau writes ‘QSB5.9I’.
EngineCummins QSB6.78,9Predecessor Swift Trawler 34 Fly, 2016 lists for Europe and North America: 425 hp (313 kW) on a shaft with a 5-blade propeller—Beneteau’s documents do not say when the 34 changed from the QSB5.9 to the QSB6.7; read the engine plate before ordering parts.
Steering—2Standard: hydraulic steering with a hung stainless-steel rudder, wheels in the wheelhouse and on the flybridge; make not named—
Trim tabs—2,3Standard: electric trim tabs, with tab indicators on the wheelhouse dashboard; make not named—
Trim tabsZipwake2,3Option in the 2024 lists: Zipwake automatic trim system—
Bow thrusterQuick BTQ 185-65-121,10,2,8,9Standard. Swift Trawler 35: make and model named only in the provisional list of July 2017; from 2018 the lists just say ‘bow thruster’ · Predecessor Swift Trawler 34 Fly: the same unit in the 2016 lists—Later boats may have a different thruster: check the unit on board before ordering a motor, propeller or control.
Stern thrusterQuick BTQ 185-65-121,10,3,2,8,9Option in Europe (make and model named only in the July 2017 list), standard in the North American lists of 2018 and 2024 · Predecessor Swift Trawler 34 Fly, 2016 lists: the same Quick unit with controls at both helms as a European option, standard in North America—
Generator7.5 kVA1,2,10,3Swift Trawler 35: option in Europe, alone or in the Air Conditioning Pack (230 V / 50 Hz); standard in the North American lists of 2018 and 2024; make not named—The North American lists name the generator both as standard and inside the Air Conditioning Pack.
Generator5.5 kVA · 6 kVA · 7.5 kVA6,7,8,9Predecessor Swift Trawler 34: 5.5 kVA as an option in the 2009 and 2010 lists; in the 2016 lists 6 kVA, 220 V, with sound shield as a European option (the plan in the same list still shows 5.5 kVA) and 7.5 kVA, 110 V / 60 Hz, as standard in North America; make not named—
Air conditioning34000 BTU2,3Swift Trawler 35: option, alone or in the Air Conditioning Pack with the 7.5 kVA generator; reversible, so it also heats; make not named—
Air conditioning—6,7,8,9Predecessor Swift Trawler 34, option: 16000 BTU in the wheelhouse plus 12000 BTU for the cabins (220 V or 110 V) in the 2009 and 2010 lists; 16000 BTU in the wheelhouse plus 6000 BTU for each cabin in the 2016 lists; make not named—
Heater5500 W2,3Option: forced-air diesel heater (‘air pulse’ in the North American lists); make not named—
Water heater25 l2,3Standard: 25 l (7 US gal), heated by the engine’s cooling circuit and on shore power (220 V; 110 V in North America); make not named—Away from shore power the water is only heated while the engine runs, unless a generator is fitted (standard in North America, an option in Europe).
Windlass1000 W2,10,3,1Swift Trawler 35: in the Essential pack in Europe (‘Essential Confort’ in the 2024 list), standard in the North American lists; controls at both helms; make not named—The optional mooring kit has a 16 kg Delta anchor and 28 m of 10 mm chain.
AutopilotRaymarine p70RS2,3,1,8,9Swift Trawler 35, option: with a repeater on the flybridge (Pack Upgrade Electronic in Europe, Essential trim package in North America) · Predecessor Swift Trawler 34 Fly, 2016 lists: also the p70RS—Beneteau names only the control head; check the course computer and drive on board before ordering parts.
AutopilotRaymarine ST706,7Predecessor Swift Trawler 34 and 34 S, 2009 and 2010 lists: in the ‘Avantage Elegance’ pack, with a repeater on the flybridge of the 34—
ChartplotterRaymarine 9″ · 12″1,2,10,3Swift Trawler 35, option: 9″ multifunction displays in the wheelhouse (with DownVision sounder) and on the flybridge in the Essential pack (Europe) or Essential trim package (North America); 12″ screens in their place as an upgrade; display models not named—Other options: Raymarine Quantum radar, Raymarine ClearCruise augmented reality (later lists), an M200 thermal camera (2017 and 2018 lists), a VHF set with AIS and an IP rear camera.
ChartplotterRaymarine C90W6,7Predecessor Swift Trawler 34 and 34 S, 2009 and 2010 lists: GPS multifunction display in the ‘Avantage Elegance’ pack, two of them on the 34 S—
ChartplotterRaymarine es97 · es1278,9Predecessor Swift Trawler 34 Fly, 2016 lists: es97 in the wheelhouse and on the flybridge (option, Essential Lounge pack), es127 in the wheelhouse as an upgrade; the North American ‘Great Loop Edition’ pack adds an AIS 650 and a dual-station Ray260 VHF—
ToiletQuiet Flush deluxe2,3,8Standard: electric toilet with a fresh-water / sea-water switch, 88 l rigid holding tank · Predecessor Swift Trawler 34: ‘Quiet Flush’ electric toilet with an 88 l holding tank—Beneteau names the toilet range but not its maker; read the label on the toilet before ordering a pump or seals.
Fridge130 l2,3Standard: front-opening 12 V fridge in the galley; options: 30 l refrigerated drawer on the flybridge, 75 l freezer drawer with ice maker; make not named—
Batteries2 × 12 V 50 Ah · 12 V 140 Ah2,3Standard: two 12 V 50 Ah engine batteries and one 12 V 140 Ah service battery (AGM in the North American list), with a battery charger; makes not named—A 700 VA inverter was part of the Essential pack.
Remote monitoringSeanapps2,3,11Standard in the 2024 lists (‘Smart Board’): connected unit and app for the boat’s status, alerts and maintenance advice; earlier boats may not have it—What it reports (GPS position, batteries, engine and navigation data) depends on how the boat is equipped.

Specifications

Length overall11.29 m (37’0″); predecessor Swift Trawler 34: 10.98 m (36’) with swim platform, 11.14 m in the 2009 and 2010 lists2,12,6,7
Hull length10.81 m (35’6″); predecessor 9.98 m (32’9″)2,12
Beam4.03 m (13’3″) overall, hull 3.96 m (13’); predecessor 4.00 m (13’1″) overall2,12,8
Draft1.17 m (3’10″); predecessor 1.00 m (3’3″)2,12
Air draft5.50 m (18’1″) maximum; predecessor 3.62 m with the mast lowered, 7.64 m with it raised (34 S: 3.32 m / 4.41 m)2,12
Displacement8252 kg (18187 lb) light displacement (EC); predecessor 7450 kg (16420 lb), 34 S 7273 kg (16030 lb)2,12
Fuel tank800 l (211 US gal), aluminium, pre-fitted for a fuel-polishing (FPS) connection; predecessor also 800 l2,12
Water tank2 × 150 l (2 × 40 US gal); predecessor 320 l (85 US gal)2,12,8
Holding tank88 l (23 US gal), rigid; grey water: 8 l buffer tank, 2 × 80 l tanks as an option · predecessor also 88 l2,12
Maximum speedSwift Trawler 35: no figure from Beneteau · Predecessor Swift Trawler 34: 22 kn with the single Cummins of 425 hp (Beneteau’s launch page, 2009)13
Engine options1 × Cummins QSB6.7, 425 hp (313 kW), the only engine offered and the maximum certified power · Predecessor: 1 × Cummins QSB5.9 of 425 hp (330 hp in the January 2010 list of the 34 S), QSB6.7 of 425 hp in the 2016 lists2,3,1,6,7,8
DriveShaft line with one propeller (size and make not stated), hung stainless-steel rudder, hydraulic steering; predecessor: shaft line with a 4-blade propeller in 2009, 5-blade in 20162,6,8
Berths4 in two cabins (double 2.00 × 1.50 m, bunks 0.70 × 1.90 m), plus the saloon settee, which converts to a 1.20 × 2.00 m double2
Cabins2: owner’s cabin forward, guest cabin with bunks to port; one head with shower to starboard2
HeadroomSaloon and galley 1.96 m, owner’s cabin 1.97 m, guest cabin 1.95 m, head 1.92 m2
CE categoryB (8 people), C (10), D (11); the same on the predecessor2,8
DesignerNaval architecture: Beneteau Power; exterior and interior design: Andreani Design · Predecessor: Beneteau Power, interior by Joubert-Nivelt2,8,14
BuilderBeneteau (SPBI), France2
HullSandwich of polyester resin and glass fibre with balsa core, structural counter-moulding in solid laminate; deck also a balsa-cored sandwich; semi-planing hull2,3
VersionsOne version, with flybridge; the lists from July 2017 to 2024 keep the same hull, engine and tanks and change only trim, upholstery and packs · Predecessor Swift Trawler 34: Fly, and from 2010 the 34 S without a helm on the flybridge · Successor Swift Trawler 37 (Fly and Sedan, 2025), not covered here1,2,14,7,15
Years built2017–2025: provisional equipment list of 24 July 2017, model page online from July 2017, last lists 2024; replaced by the Swift Trawler 37, announced in June 2025 · Predecessor Swift Trawler 34: new for autumn 2009, 34 S list from January 2010, last lists July 20161,16,2,15,13,7,8
Hulls builtSwift Trawler 35: no figure from Beneteau · Predecessor Swift Trawler 34: more than 350 (Beneteau)14

Good to know

  • Every Swift Trawler 35 has the same single Cummins QSB6.7 of 425 hp on a shaft, with a fuel filter with water separator and a sea-water filter, so filters, impellers and engine service parts are Cummins items. Beneteau’s help centre says only the engine maker or its local representative can supply documents and certificates for the engine, so ask a Cummins dealer for the engine manuals.2,5
  • Thrusters and generator depend on the market: the North American lists have the stern thruster and a 7.5 kVA generator as standard, the European ones only the bow thruster, with the rest as options. Check what is actually fitted. On early boats the bow thruster is a Quick BTQ 185-65-12, and the optional stern thruster was the same unit.10,3,2,1
  • The 800 l aluminium fuel tank came pre-fitted for a fuel-polishing system, and the engine has a fuel filter with water separator. With only one engine, clean fuel matters: ask whether a polishing system was added, and drain the separator bowl regularly.2
  • As standard the grey water goes only to an 8 l buffer tank; two 80 l grey-water tanks with deck or overboard emptying were an option. Worth checking if you cruise where grey-water discharge is restricted.2
  • Hull and deck are a polyester and glass-fibre sandwich with a balsa core, according to Beneteau’s construction spec. At a survey, have moisture readings taken around deck fittings, the bow roller, stanchion and ladder bases and any holes drilled later.2
  • Beneteau does not publish the owner’s manual online. Ask the selling dealer, or e-mail Beneteau (info@beneteau.fr) for a PDF copy, as its help centre explains. The last equipment lists and the e-brochure can still be downloaded from the model page.17,4
