Yamaha · Outboard
Yamaha Enduro 15
The Yamaha Enduro E15D is a 246 cc two-cylinder two-stroke of 15 hp with recoil start, tiller and a separate tank; Yamaha’s parts catalogue lists it as model type 6B41, together with its 9.9 hp twin, the E9.9D. Yamaha builds it as a heavy-duty engine for fishing and work boats and still sells it in Africa, the Pacific, Asia and Latin America, and long-distance cruisers know it as the classic dinghy engine that keeps running far from any dealer. The leisure 15F and 9.9F share the same engine but take a different water pump kit and impeller, gearcase anode, gasket kits and spark plug. The larger Enduro E25B is a different engine that shares only the fuel filter.
- Manuals & documents
- Wear parts & part numbers
- Service intervals
- Specifications
- Good to know
- On the marketplace
Manuals & documents
The links go straight to Yamaha. We host no manuals or drawings — the manufacturer’s copy is the current one.
- Owner’s manual 9.9F / 15F two-stroke (63V-28199-7L, 2020): the leisure version of the same engine Operation manual cdn2.yamaha-motor.eu · PDF · EN · FR · ES
- Yamaha parts catalogue (YPEC): search “E15D” for model type 6B41, which also covers the E9.9D, with the repair kits Parts catalogue ypec-sss.yamaha-motor.co.jp · EN
- Yamaha Motor Canada: parts catalogue entry page (opens YPEC) Manual portal yamaha-motor.ca · EN
- Yamaha Motor Europe owner’s manual library (15F / 9.9F editions 2013–2020; no Enduro manual listed) Manual portal yamaha-motor.eu · EN
- Yamaha: Enduro models 30–8 hp, main specifications (E15D, E9.9D, E25B, E30H, E8D) Product page global.yamaha-motor.com · EN
- Yamaha South Africa: E15 Enduro product page Product page yamaha.co.za · EN
- Yamaha: two-strokes 15–4 hp, main specifications (leisure 15F and 9.9F) Product page global.yamaha-motor.com · EN
Wear parts & part numbers
| Part | OEM number | Also fits | Note |
|---|---|---|---|
| Water pump repair kit | 6B4-W0078-0A1 | — | Enduro E15D and E9.9D: impeller, cartridge insert, outer plate, gaskets, key and damper. Not for the leisure 15F/9.9F, which takes 63V-W0078-01. |
| Raw water pump impeller | 682-44352-031,2replaces 682-44352-02 | — | E15D and E9.9D; also inside kit 6B4-W0078-0A. Replaces 682-44352-02 (per Wholesale Marine). The leisure 15F takes 63V-44352-01. |
| Water pump gaskets | 682-44315-A01 | — | E15D and E9.9D, two per pump; also in the water pump kit and in the lower-unit kit 6B4-W0001-20. |
| Water pump liner (sleeve) | 682-44322-411 | — | Cartridge insert for E15D and E9.9D; also in kit 6B4-W0078-0A. |
| Thermostat | 6E5-12411-301 | — | E15D, E9.9D and the leisure 15F/9.9F (catalogues 2003–2012). |
| Thermostat gasket | 682-12414-A11 | — | Thermostat cover gasket; E15D, E9.9D and 15F/9.9F; also in the power-head gasket kit. |
| Anode (engine) | 682-11325-001 | — | Cylinder head anode; E15D, E9.9D and 15F/9.9F. |
| Anode (lower unit) | 6B4-45251-001 | — | Gearcase anode, Enduro E15D and E9.9D only; the leisure 15F takes 61N-45251-01. |
| Spark plug | 94702-001601 | — | NGK B8HS-10, two per engine, standard on E15D and E9.9D. Caribbean-specification engines take the resistor plug NGK BR8HS-10 (94702-00247); the leisure 15F takes BR7HS-10 (94702-00271). |
| Fuel filter (engine) | 61N-24560-001 | — | In-line filter assembly with clear cup; fits E15D, E9.9D, 15F and E25B. Cup 61N-24521-00, cup O-ring 93210-32738. |
| Fuel filter (engine) | 61N-24563-001 | — | Filter element only, for assembly 61N-24560-00 (E15D, E9.9D, 15F). |
| Carburettor repair kit | 63V-W0093-001 | — | E15D and E9.9D (also the 2003 and Oceania-market 15F; later Canadian-market 15F list 63V-W0093-10). The main jet is not in the kit: E15D #108 = 676-14943-79, E9.9D #110 = 676-14943-29. |
| Gasket set | 6B4-W0001-001 | — | Power-head gasket kit for E15D and E9.9D: head, cylinder, exhaust cover and thermostat gaskets and crankshaft seals. The 15F takes 63V-W0001-02. |
| Lower unit seal kit | 6B4-W0001-201 | — | Lower-unit gaskets and seals for E15D and E9.9D: upper casing and pump gaskets, drain-plug gaskets, propeller-shaft and drive-shaft seals. The 15F takes 63V-W0001-22. |
| Gear oil plug gaskets | 90430-080201 | — | One for each of the three plugs (90340-08002) on the E15D/E9.9D gearcase; also in the lower-unit kit. |
| Starter rope | 63V-15751-001 | — | 1.8 m rope for the E15D and E9.9D recoil starter. |
| Propeller hardware kit | 90171-10M01 · 91490-300201,3 | — | Castle nut and cotter pin, E15D, E9.9D and 15F. Tighten the nut to 17 N·m, turn it on to the next slot and fit a new cotter pin every time the propeller has been off. |
| Propeller | 683-45941-00-EL · 683-45943-00-EL · 683-45952-00-EL · 683-45947-00-EL · 683-45949-00-EL1 | — | 3-blade aluminium, mark J, for E15D and E9.9D (also listed for the 15F); in the order listed 9¼ × 12, 9¼ × 10½, 9¼ × 9¾, 9¼ × 8 and 9½ × 6½ in (diameter × pitch). |
| Propeller | 63V-45943-00-EL · 63V-45952-00-EL · 63V-45945-00-EL · 63V-45947-00-EL1 | — | Also listed for E15D and E9.9D: 9¼ in diameter, 11, 10, 9 and 8 in pitch in the order listed. |
| Propeller | 683-W4591-02-EL · 683-W4592-02-EL1 | — | Low-pitch versions for E15D and E9.9D, supplied with their own deflector ring and nut: 9¾ × 8 and 9¾ × 6½ in, in the order listed. |
Numbers checked against the sources below on 12 October 2026. Always confirm against your serial number and exact type before ordering.
Service intervals
| Task | Interval |
|---|---|
| Gear oil change | First after 20 h or 3 months, then every 100 h or yearly3 |
| Spark plug | Check, clean and regap or replace every 100 h or yearly3 |
| Raw water impeller | Impeller and pump housing: check every 100 h or yearly, replace every 300 h or 3 years3 |
| Thermostat | Check every 100 h or yearly3 |
| Anode | Outer (gearcase) anode: check every 100 h or yearly; anodes in the cylinder head and thermostat cover: check every 500 h or 5 years3 |
| Fuel filter | Check at 20 h, then every 100 h or yearly; replace as needed3 |
| Fuel pump | Fuel pump on the carburettor: check every 300 h or 3 years3 |
| Lubrication | Grease the greasing points at 20 h, then every 100 h or yearly3 |
| Propeller | Propeller, nut and cotter pin: check at 20 h, then every 100 h or yearly3 |
| Exhaust | Exhaust guide and exhaust manifold: check every 1000 h3 |
| Fresh-water wash | Flush the cooling system with fresh water after every use in salt, muddy or acidic water3 |
Yamaha’s manual libraries list no Enduro manual, so these intervals come from the chart in Yamaha Europe’s owner’s manual 63V-28199-7L-E0 (2020) for the leisure 15F/9.9F, which has the same 246 cc engine; the E15D’s own chart from 2003 could not be read reliably. Hours or months, whichever comes first. The chart assumes about 100 hours a year; for long days at high load, frequent starts or trolling Yamaha asks for the work twice as often, which fits typical Enduro use.
Specifications
| Type | Two-stroke, two cylinders in line, one carburettor with manual choke, premix lubrication4 |
|---|---|
| Displacement | 246 cc (15.0 cu in)5 |
| Bore × stroke | 56.0 × 50.0 mm5 |
| Compression ratio | 7.0:14 |
| Power | E15D: 11.0 kW (15 hp) at 5000 rpm; E9.9D: 7.3 kW (9.9 hp) at 5000 rpm5 |
| Full-throttle range | 4500–5500 rpm (figure from the 15F manual; dealer data for the E15DMHL gives the same)3 |
| Ignition | CDI with flywheel magneto (charge and pulser coils), no battery needed for the recoil-start engine; reed-valve intake1 |
| Cooling | Raw water: rubber-impeller pump in the gearcase with a chrome-plated housing, thermostat in the cylinder head, tell-tale (cooling-water pilot) hole4 |
| Fuel | Unleaded petrol premixed 50:1 (2 %) with two-stroke outboard oil, per a Yamaha dealer’s page (Budget Marine); Yamaha’s leisure 15F uses 50:1 only for break-in and 100:1 after6,3 |
| Engine oil grade | Two-stroke outboard oil: Yamalube 2-stroke or another NMMA TC-W3 certified oil (as the 15F manual specifies for the same engine)3 |
| Fuel tank | Separate portable tank; Yamaha’s catalogue lists a 24 l tank with fuel line and primer bulb1 |
| Gear ratio | 2.08:1 (27:13); forward, neutral and reverse1 |
| Gear oil capacity | 0.25 l (figure from the 15F manual, same gearcase size)3 |
| Gear oil grade | Hypoid gear oil SAE 90, API GL-4 (Yamalube outboard gear oil)3 |
| Spark plug | NGK B8HS-10, two per engine; Caribbean-specification engines NGK BR8HS-10; gap 0.9–1.0 mm1 |
| Tightening torques | Spark plug 25 N·m; propeller nut 17 N·m, then on to the next slot with a new cotter pin; outer anode bolts 7 N·m (figures from the 15F manual)3 |
| Alternator | Optional 80 W lighting coil4 |
| Propeller | 3-blade aluminium, mark J, 9¼ in diameter (9½–9¾ in on the low-pitch versions), 6½ to 12 in pitch; held by a castle nut and cotter pin, no shear pin1 |
| Shaft length | S 441 mm (17.4 in), L 568 mm (22.4 in), X 710 mm (E15D only; the E9.9D comes in S and L)5 |
| Dry weight | E15D 38–41 kg depending on shaft; E9.9D 38–40 kg (with propeller)5 |
| Models | E15DMHS, E15DMHL, E15DMHX (Yamaha model type 6B41); E9.9DMHS, E9.9DMHL (6B31); Caribbean-specification engines have a resistor plug and a different ignition coil1,5 |
| Versions | E15D and E9.9D share every service part on this page; the E9.9D differs in main jet (#110 instead of #108), reed valve assembly and cowling. The leisure 15F has the same engine but its own water pump kit and impeller, gearcase anode, gasket kits and spark plug, and runs 100:1 after break-in. The E25B is a different engine that shares only the fuel filter.1,3 |
| Years built | Since the 2003 model year (first year in Yamaha’s parts catalogue); still in Yamaha’s Enduro range1,5 |
Good to know
- Order wear parts by model code, not by “15 hp two-stroke”: the Enduro E15D/E9.9D takes water pump kit 6B4-W0078-0A, impeller 682-44352-03 and gearcase anode 6B4-45251-00, while the look-alike leisure 15F takes 63V-W0078-01, 63V-44352-01 and 61N-45251-01.1
- Mix the Enduro at 50:1 (2 %). That figure comes from a Yamaha dealer’s page (Budget Marine), since Yamaha publishes no Enduro manual online; the 100:1 in the leisure 15F manual applies to the 15F after break-in, not to the Enduro.6,3
- The standard plug is a non-resistor NGK B8HS-10, one heat range colder than the leisure model’s BR7HS-10. Carry two spares gapped at 0.9–1.0 mm: a dinghy engine that spends most of its life idling fouls plugs sooner than one run hard.1
- There is no shear pin: the propeller sits on a splined shaft behind a castle nut and cotter pin (91490-30020). Keep a few spare cotter pins aboard and never reuse an old one.3,1
- Look for a steady jet from the cooling-water tell-tale every time you start. A weak stream means a worn impeller or a blocked tell-tale hole; on long passages carry a spare impeller or the complete pump kit.3
- The in-line fuel filter (61N-24560-00) has a clear cup: check it for water and dirt whenever you refuel from jerrycans of unknown quality.1
