Yamaha · Outboard
Yamaha F9.9
The Yamaha F9.9 is a 212 cc in-line twin four-stroke with a single overhead camshaft, four valves, one carburettor and CDI ignition, and one of the most common small outboards on tenders, RIBs and small fishing boats; with a long or extra-long shaft it also pushes small cruising yachts. This page covers the whole family built on that engine: the F9.9F (2007–2012, developed from the 8 hp F8C with a larger displacement), the restyled F9.9J with a multi-function tiller (2013 to date), the 8 hp F8F (2015 to date) and the High Thrust T9.9 (sold as FT9.9G, FT9.9L and T9.9), which has a larger 2.92:1 gearcase and an 11¾ in propeller for heavy boats. The powerhead parts are the same on all of them, while the High Thrust gearcase takes its own water pump kit, impeller, anode, seal kit and propeller and more gear oil. The 362 cc F9.9H sold in Europe, which is based on the F15/F20, and the F9.9 generations before 2007 are different engines and not covered here.
- Manuals & documents
- Wear parts & part numbers
- Service intervals
- Specifications
- Good to know
- On the marketplace
Manuals & documents
The links go straight to Yamaha. We host no manuals or drawings — the manufacturer’s copy is the current one.
- Owner’s manual F9.9 / T9.9 (6DR-28199-7A-E0, 2026 model year) Operation manual cdn2.yamaha-motor.eu · PDF · EN
- Owner’s manual F9.9J / FT9.9L (6DR-28199-72-E0, 2015 edition) Operation manual cdn2.yamaha-motor.eu · PDF · EN
- Owner’s manual F6 / F8 / T8 (6FW-28199-79-E0, 2026 model year) Operation manual cdn2.yamaha-motor.eu · PDF · EN
- Owner’s manual F9.9F / FT9.9G (6AU-28199-75-G0, 2012 model year; German) Operation manual cdn2.yamaha-motor.eu · PDF · DE
- Yamaha Motor Europe owner’s manual library: Outboard Engines, 2.5 to 20 hp, model F(T)9.9 or F(T)8 (many languages) Manual portal yamaha-motor.eu · EN
- Yamaha Outboards (US): owner’s manual by Primary ID (model code, shaft and serial number) Manual portal yamahaoutboards.com · EN
- Yamaha parts catalogue (YPEC): F9.9F, F9.9J, F8F, FT9.9G, FT9.9L, with scheduled service parts and repair kits for every model year 2008–2026 Parts catalogue ypec-sss.yamaha-motor.co.jp · EN
- YamahaPubs: printed owner’s and service manuals from Yamaha USA Manual portal yamahapubs.com · EN
- Yamaha Outboards (US): 9.9 hp and 8 hp portables, specifications Product page yamahaoutboards.com · EN
- Yamaha Outboards (US): High Thrust T9.9, specifications Product page yamahaoutboards.com · EN
- F9.9J factsheet, Yamaha Motor Europe (2017) Brochure cdn2.yamaha-motor.eu · PDF · EN
- FT9.9L High Thrust factsheet, Yamaha Motor Europe (2017) Brochure cdn2.yamaha-motor.eu · PDF · EN
Wear parts & part numbers
| Part | OEM number | Also fits | Note |
|---|---|---|---|
| Water pump repair kit | 68T-W0078-022,3,4replaces 68T-W0078-00replaces 68T-W0078-01 | Sierra 18-34501 | Standard gearcase (2.08:1): F9.9F, F9.9J and F8F, all years; not for the High Thrust T9.9. Contains impeller 68T-44352-00, cartridge insert 63V-44322-00, outer plate 68T-44323-00, water seal damper 68T-44366-01, Woodruff key 664-44338-00, O-ring 93210-44398 and four bolts 97D95-08045. Yamaha lists -00 up to the 2018 model year, -01 for 2019–2020 and -02 from 2021; dealers supply -02 for all years (US dealers write 68T-W0078-02-00). |
| Water pump repair kit | 69G-W0078-022,5replaces 69G-W0078-00replaces 69G-W0078-01 | — | High Thrust gearcase (2.92:1) only: FT9.9G, FT9.9L and T9.9, all years. Same number history as the standard kit (-00 up to 2018, -01 for 2019–2020, -02 from 2021). Contains the High Thrust impeller 63V-44352-01. |
| Raw water pump impeller | 68T-44352-002,1 | Sierra 18-89101 | Standard gearcase: F9.9F, F9.9J, F8F; also inside kit 68T-W0078. Sierra names 18-8910 as the impeller of its 18-3450 kit for these engines. |
| Raw water pump impeller | 63V-44352-012 | — | High Thrust gearcase only (FT9.9G, FT9.9L, T9.9); also inside kit 69G-W0078. |
| Spark plug | 94702-002742,4,6 | NGK BR6HS-102,6,7 | An NGK BR6HS-10 under Yamaha’s number; two per engine, all models and years. Gap 0.9–1.0 mm, 24 N·m. |
| Thermostat | 66M-12411-012,4 | — | All F9.9F, F9.9J, F8F and T9.9 in the 2008–2026 catalogues. |
| Thermostat gasket | 6G8-12414-A0 · 688-12412-002,4 | — | Cover gasket 6G8-12414-A0 (on Yamaha’s scheduled service parts list) and the rubber seal 688-12412-00 that sits on the thermostat; all models. |
| Anode (engine) | 6G8-11325-002,4 | — | Internal anode in the cylinder head, all models; replace every 500 h or 5 years. |
| Anode (lower unit) | 68T-45251-002,4 | — | External gearcase anode, standard gearcase: F9.9F, F9.9J, F8F. |
| Anode (lower unit) | 61N-45251-012 | — | External gearcase anode, High Thrust only (FT9.9G, FT9.9L, T9.9). |
| Fuel filter (engine) | 68T-24251-012,8,4replaces 68T-24251-00 | — | Disposable in-line filter under the cowling, all models; with a portable tank it is the only fuel filter. The 2008 catalogues for the F9.9F and FT9.9G still list 68T-24251-00; US dealers write 68T-24251-01-00. |
| Engine oil strainer | 68T-13421-012 | — | Strainer built into the oil pan; there is no spin-on oil filter. Yamaha leaves checking and cleaning it to the dealer, every 100 h or yearly. |
| Drain plug gasket | 90430-10M112,4 | — | Engine oil drain screw gasket, all models; fit a new one at every oil change. The drain screw itself is 90340-10M10. |
| Gear oil plug gaskets | 90430-080032,4 | — | Two per gearcase, for the drain and level plugs (90340-08002); standard and High Thrust. |
| Timing belt | 68T-46241-002 | — | Toothed belt driving the camshaft, all models in the 2008–2026 catalogues (the 2008 catalogue calls it a ‘V-belt’). Yamaha: check yearly, replace at 1000 h. |
| Carburettor repair kit | 6DR-W0093-002 | — | 2013 on: F9.9J, F8F and FT9.9L/T9.9 (float, needle valve, gaskets and O-rings). |
| Carburettor repair kit | 6AU-W0093-002 | — | 2007–2012: F9.9F and FT9.9G (model codes 6AU and 6AV). |
| Gasket set | 6AU-W0001-002 | — | Powerhead gasket kit, all models (F9.9F, F9.9J, F8F, T9.9). |
| Lower unit seal kit | 68T-W0001-202 | — | Gaskets and seals for the standard gearcase: F9.9F, F9.9J, F8F. |
| Lower unit seal kit | 69G-W0001-202 | — | Gaskets and seals for the High Thrust gearcase only (FT9.9G, FT9.9L, T9.9). |
| Propeller | 6G1-45947-00 · 6G1-45943-00 · 6G1-45952-00 · 6G1-45941-00 · 6G1-45954-002 | — | Standard gearcase (F9.9F, F9.9J, F8F): 3-blade aluminium, 8½ in diameter, mark N; in the order listed 6½, 7½, 8, 8½ and 9¼ in pitch. Choose the pitch that lets the engine reach 5000–6000 rpm at full throttle. |
| Propeller | 6G1-W4592-00 · 6G1-W4591-012 | — | Standard gearcase: 9 in diameter versions, 5 in and 7 in pitch in the order listed. |
| Propeller | 69G-45943-002 | — | High Thrust (FT9.9G, FT9.9L, T9.9): 3-blade, 11¾ in diameter, 7 in pitch, mark R; the only propeller in the current T9.9 catalogue. |
Numbers checked against the sources below on 12 October 2026. Always confirm against your serial number and exact type before ordering.
Service intervals
| Task | Interval |
|---|---|
| Engine oil change | First after 20 h or 3 months, then every 100 h or yearly7 |
| Strainer clean | Oil strainer in the oil pan: check and clean every 100 h or yearly (dealer)7 |
| Gear oil change | First after 20 h or 3 months, then every 100 h or yearly7 |
| Fuel filter | In-line filter: replace every 100 h or yearly; check it for dirt and water in between7 |
| Fuel pump | Check every 300 h or 3 years (dealer)7 |
| Spark plug | Check, clean or replace every 100 h or yearly7 |
| Raw water impeller | Impeller and pump housing: check every 100 h or yearly, replace every 300 h or 3 years7 |
| Thermostat | Check every 100 h or yearly7 |
| Anode | External anodes: check every 100 h or yearly; cylinder-head anode: check every 100 h, replace every 500 h or 5 years7 |
| Timing belt | Check every 100 h or yearly; replace at 1000 h7 |
| Valve clearance | Check and adjust every 500 h or 5 years7 |
| Lubrication | Greasing points (swivel bracket, tilt, clamp screws, shift and throttle linkage): first after 20 h or 3 months, then every 100 h or yearly7 |
| Exhaust | Exhaust guide and exhaust manifold: check every 1000 h7 |
| Fresh-water wash | Flush the cooling system with fresh water after every use in salt, muddy or brackish water7 |
Hours or months, whichever comes first, from Yamaha’s F9.9/T9.9 owner’s manual (6DR-28199-7A-E0, 2026 model year); the 2015 edition (6DR-28199-72-E0) has the same chart. Under severe use (long trolling, constant full throttle, frequent starts) Yamaha halves every interval, e.g. 50 h instead of 100 h.
Specifications
| Type | Four-stroke, single overhead camshaft (SOHC), 4 valves, one carburettor with choke, wet sump7 |
|---|---|
| Cylinders | 2, in line7 |
| Displacement | 212 cc (12.9 cu in)7,9 |
| Bore × stroke | 56.0 × 43.0 mm7 |
| Compression ratio | 9.4:16 |
| Power | F9.9 and T9.9: 7.3 kW (9.9 hp); F8: 5.9 kW (8 hp)7,9 |
| Full-throttle range | 5000–6000 rpm7 |
| Idle speed | 1000–1100 rpm in neutral7 |
| Ignition | CDI7 |
| Cooling | Raw water: rubber-impeller pump in the gearcase, thermostat; garden-hose flushing connector on the bottom cowling7 |
| Engine oil capacity | 0.8 l (0.85 US qt)7,6 |
| Engine oil grade | Yamalube 4 (Yamalube 4M in the US) or another four-stroke outboard oil, SAE 10W-30, 10W-40 or 5W-30, API SE to SL; if none of these is available, SAE 15W-40, 20W-40 or 20W-50, API SH to SL7 |
| Gear ratio | F9.9 and F8: 2.08:1 (27:13), propeller mark N; High Thrust T9.9: 2.92:1 (38:13), propeller mark R7 |
| Gear oil capacity | F9.9 and F8: 0.150 l; High Thrust T9.9: 0.370 l7 |
| Gear oil grade | Yamalube outboard gear oil or hypoid gear oil SAE 90, API GL-47 |
| Spark plug | NGK BR6HS-10, two per engine7,6 |
| Spark plug gap | 0.9–1.0 mm7 |
| Valve clearance (cold) | Intake 0.15–0.20 mm, exhaust 0.20–0.25 mm7 |
| Alternator | Maximum charging output 6 A7 |
| Fuel | Unleaded petrol, at least 90 RON (Yamaha USA: 87 octane, at most 10 % ethanol), from a separate portable tank (Yamaha 12 l tank)7,6 |
| Shaft length | F9.9 and F8: transom height S 431 mm, L 558 mm (sold as 15 and 20 in shafts in North America); T9.9: L 552–557 mm (20 in), X 620–625 mm (25 in)7,6 |
| Dry weight | With aluminium propeller: F9.9 tiller with pull start 40 kg (S) / 41 kg (L); F9.9 electric start 42 / 43 kg; T9.9 45–46 kg, with power tilt 49–50 kg7 |
| Tightening torques | Spark plug 24 N·m, oil drain screw 24 N·m, gear oil plugs 7 N·m, propeller nut 17 N·m (F9.9) or 21 N·m (T9.9), always with a new cotter pin7 |
| Models | Model code on the serial plate: 6AU = F9.9F, 6DR = F9.9J, 6FW = F8F, 6AV = FT9.9G, 6EA = FT9.9L/T9.9. Current names in Europe: F9.9MHB, F9.9EB, F8MHB, F8EB, T9.9MHB, T9.9EB, T9.9PB; in North America e.g. F9.9SMHB, F9.9LMHB, F9.9SEHB, F9.9LEHB, F9.9LEB, F8SMHB, F8LMHB, T9.9LMHB, T9.9LEB, T9.9LPB, T9.9XPB, T9.9XEB2,7,6 |
| Versions | F9.9F from 2007, developed from the F8C with a larger displacement; F9.9J from March 2013 with the same 212 cc engine, a multi-function tiller with shift lever and stop switch and a restyled cowling; still built in 2026, in North America as “B” models such as the F9.9LMHB10,11 |
| Years built | F9.9F 2007–2012 (on sale from May 2007), F9.9J since March 2013, F8F since 2015; High Thrust on this engine since the 2008 model year (FT9.9G 2008–2012, FT9.9L/T9.9 since 2013); still in production10,11,2 |
Good to know
- Check which gearcase you have before ordering cooling or gearcase parts. The standard F9.9 and F8 (propeller mark N, 2.08:1) take 150 ml of gear oil and water pump kit 68T-W0078. The High Thrust T9.9 (mark R, 2.92:1, 11¾ in propeller) takes 370 ml and needs kit 69G-W0078, impeller 63V-44352-01 and gearcase anode 61N-45251-01.2,7
- The model code on the serial plate tells you the generation: 6AU is an F9.9F (2007–2012), 6DR an F9.9J (2013 on), 6FW an F8F, 6AV or 6EA a High Thrust T9.9. A European F9.9H (code 6AG) is a 362 cc engine based on the F15/F20 and takes different parts, including a DPR6EB-9 spark plug.12,2
- There is no screw-on oil filter to buy: an oil change takes 0.8 litres of oil and a new drain screw gasket (90430-10M11). Yamaha suggests pumping the old oil out through the dipstick tube with an oil extractor, so nothing spills from the drain screw while the engine hangs on the transom. The strainer in the oil pan is a dealer job at the annual service.7
- To change the gear oil, pump it in through the lower drain hole until it runs out of the upper level hole, then fit the level plug first and the drain plug last, each with a new 90430-08003 gasket. If the old oil is milky or full of metal particles, water or wear is getting into the gearcase; have it checked before the next season.7
- Flush with the engine stopped: screw a garden hose onto the connector on the bottom cowling and let fresh water run for about 15 minutes after every trip in salt water. Screw the connector back on firmly afterwards; a loose connector leaks cooling water and the engine can overheat.7
- Watch for a steady jet from the cooling-water pilot hole whenever the engine runs. If it weakens or stops, shut down and check the water inlet on the gearcase and the pilot hole for blockages; if both are clear, have the pump looked at. Yamaha checks the impeller every year and replaces it every three years; on a tender that runs in sandy water, a spare kit on board is cheap insurance.7
